Ikelite Nikon Z50 II Housing

Underwater Housing for Nikon Mirrorless Cameras

Dive in with Nikon mirrorless cameras using a lightweight and fully featured underwater housing. No other manufacturer makes professional functionality so accessible. Our housings are designed from the ground up to provide full camera control and connection for external strobe lighting out of the box. Advanced features, including TTL lighting exposure and enhanced magnifying viewfinders, are available as needed.

The Housing

Our DL-series lens ports are optimised to be the lightest on the market, while ensuring superb image quality. The materials chosen for our housings and lens ports maximise durability and corrosion resistance, while minimising travel weight and cost.

Specifications

• Model: Nikon Mirrorless Camera Underwater Housing
• Material: Custom ABS-PC blend (lightweight and durable)
• Depth Rating: 200 feet (60 metres)
• Weight: 5.45 lb (2.47 kg)
• Dimensions: 9 x 7 x 6.25" (229 x 178 x 159 mm)
• Lens Ports: DL (Dry Lock) system
• Strobe Connector: Ikelite Bulkhead with Manual Hotshoe and Fibre Optic Ports
• Accessory Port: M16 Thread

Controls

The housing provides controls for all camera functions except: Fn1, Fn2, Flash pop-up, Diopter adjustment dial, and Touchscreen.

Pre-Dive Checks

There is no greater assurance than being able to see your camera and o-ring seal through the back of the housing. Our signature open-groove design suspends the rear o-ring in a natural position that is easier to maintain and more reliable than forcing the o-ring into a channel. Once the housing is closed, you can see the o-ring form a solid, waterproof seal. We recommend using a pump with gauge to pull a vacuum on the housing and check for leaks prior to entering the water.

Construction

Our specially formulated ABS-PC blend housing is highly durable yet significantly lighter than aluminium. The light colour keeps your camera cooler when shooting in warm, sunny environments.

Lens Support

Ikelite lens ports are the lightest on the market, yet robust and capable of standing up to rough surf. We support a wide variety of lenses. Most popular zoom lenses and select focus rings can be engaged using simple gearing that puts adjustment right at your fingertips. Zoom and focus gears differ depending on which lens you are using. Lens ports and zoom gears are sold separately. Refer to the appropriate port chart for compatibility information.

Wi-Fi Transfer

Use the camera's built-in Wi-Fi feature to download photos to another device without removing the camera from the housing. The Wi-Fi feature is only usable above water within close proximity to the connected device.

Compatibility

Unless otherwise noted, this housing does not accommodate the use of add-on grips, battery grips, eyepieces, LCD covers, or other accessories. Differences in lens and control placement prevent other camera models from being used in or adapted to this housing. We are not aware of any other models which may be used in or adapted to this housing.

In the Box

• Housing
• Rear O-ring # 0132.59 (installed)
• Front O-ring # 0132.45 (installed)
• Zoom Gear Retainer # 75900 (installed)
• Port Hole Cover # 0200.92 (installed)
• Waterproof Bulkhead Cap # 9104.7 (installed)
• Base with Left-Hand Quick Release Handle # 4077.67 (installed)
• Tool for Zoom Gear Retainer # 0945.06
• .050" Hex Key # 0945.11
• 1/16" Hex Key # 0945.16
• Silicone Lubricant 1cc Tube
